Magnetostriction with the Michelson interferometerelson interferometer

Article no: P2430811

Principle

With the aid of two mirrors in a Michelson arrangement, light is brought to interference. Due to the magnetostrictive effect, one of the mirrors is shifted by variation in the magnetic field applied to a sample and the change in the interference pattern is observed.

Benefits

  • See that magnetic fields can change the geometry of objects
  • Use a Michelson interferometer to measure quantitatively this most subtile effect
  • Set up the instrument by yourself from separate components

Tasks

  1. Construction of a Michelson interferometer using separate optical components.
  2. Testing various ferromagnetic materials (iron and nickel) as well as a non-ferromagnetic material (copper), with regard to their magnetostrictive properties.

Learning objectives

  • Interference
  • Wavelength
  • Diffraction index
  • Speed of light
  • Phase
  • Virtual light source
  • Ferromagnetic material
  • Weiss molecular magnetic fields
  • Spin-orbit coupling

Scope of delivery

Optical breadboard, optimized Damping 08751-00 1
YAG Laser green, 1 mW, 532 nm for component holder 08767-99 1
Adjusting support 35 x 35 mm 08711-04 3
Surface mirror 30 x 30 mm 08711-01 4
Accesory set for optical base plate 08750-50 1
Beam splitter 1/1, non polarizing 08741-00 1
Lens made of glass, biconvex, f = + 20 mm 08059-00 1
Component holder 08043-00 2
Screen, white, 150x150 mm 09826-00 1
Faraday modulator for optical base plate beam height 15 cm 08733-02 1
Rods for magnetostriction,set 08733-01 1
PHYWE Power supply, universal, analog display DC: 18 V, 5 A / AC: 15 V, 5 A 13503-93 1
PHYWE Digital multimeter, 600V AC/DC, 10A AC/DC, 20 MΩ, 200 µF, 20 kHz, −20°C…760°C 07122-00 1
Connecting cable, 32 A, blue, various lengths 07361-04 1
Magnetic foot for optical base plate 08710-00 1
Ring for component holder 08044-00 2
